Specifications

1.Suitable for many kinds of agri waste

2.High efficiency

3.Roller & mould are made from special alloy

4.Extreme dur

Introduction:

Yugong Machinery has introduced into advanced technology,invented SJM5 flat-dies biomass briquette machine.



       This kind of machinery can produce a special coal (High efficiency fuel) with many kinds of straw/stalks as raw material, such as rice hull, peanut hull, corn straw,sawdust and all kinds of crop straw,also the material of low adhesion rate and difficult to forming. The heat quantity caused by burning this fuel is equivalent to coal, and moreover, the quantity of carbon dioxide in smoke dust, especially the quantity of sulfur dioxide, reduces extremely. Also the cost is much lower than coal.The finished product mainly used as fuel in furnace,boiler and power plant, the clinker after burning was directly used as fertilizer. It is especially confirmed to the world market of renewable compression biomass energy demand.

       Compared to ring-dies briquetting machine---The ring dies briquetting machine is restricted by ring diameter,its roller can not be enlarged enough, roller bearing room is smaller, so the assembly bearing is not strong enough to withstand pressure,so the problems come to being:bearing's less standing ability leads to frequent repair.





Characteristic:

1.The mould & rollers are made from special alloy and processed by special method & treatment,

   so with extreme durability.Successfully overcomed the poor resistance of traditional mould &

   roller.



2.It adopts screw-center adjusting pressure structure,the pressed rollers' gap can be  adjusted

   smaller or bigger,so it can meet different materials' demand and make sure the briquetting effect.



3.Main machine equippmed with specially desinged screw conveyor which has speed control device,

   thus can realize feeding steadily and cleanly for all kinds of raw material.



4.Main machine,screw conveyor and speed control device can be operated through one combined

   control panel.Which is more convenient and labor-saving.



5.With 1 year warranty.









Specifications:

Motor Power	37kw (380V,3Phase or according to customer's requirement about voltage)
Capacity	1500-2000kgs/h (according to different raw material)
Dimension of Exterior	2290*1100*1400mm
Weight	1700kgs
Raw Material	all kinds of stalk/straw/sawdust
Length of Raw Material	2-15mm
Moisture of Raw Material	13-28%
Density of Finished Product	0.9-1.4g/cm3
Heating Capacity of Finished Product	3500-5500kcal/kg
