Wire materials: SUS302, SUS304, SUS304L, SUS310S, SUS316, SUS316L, SUS321, etc.

Wire diameters: 0.01 mm - 5 mm.

Disc diameters: 5 mm - 600 mm (custom size: 8 mm - 3800 mm).

Weaving methods: plain weave, twill weave, dutch weave, etc.

Layer: single layer or multiple layers.

Filter disc shapes: round, rectangular, square, crescent and semicircle, etc.

Marginal materials: copper, aluminum, stainless steel, rubber, etc.

Filtration precision: 0.2 µm - 100 µm.

Key features

Materials: stainless steel 304/316/316L (most common), also brass, copper, aluminum, Monel, Inconel, or duplex on request.

Construction: single-layer, multi-layer, or sintered; laser-cut or stamped; spot-welded; optional stainless/aluminum rim or edge binding to prevent fraying

Shapes and sizes: round (standard), also square, oval, and custom; typical diameters 5–500 mm; thickness per mesh/layer

Filtration rating: from around 5 μm to 2000 μm (mesh counts from coarse to fine); high open area for low pressure drop

Performance: high temperature and corrosion resistance depending on alloy; robust, cleanable, and reusable

Cleanability: backwashing, ultrasonic cleaning, or solvent cleaning depending on media and process

Compliance options: food-grade materials and documentation available on request
