FUKUDA KAP 1 10AH

　　Brand:FUKUDA

　　Category:FUKUDA

　　Product ID:2210101

　　Manufacturer Part Number:KAP1-10AH

　　Brand/Manufacturer:FUKUDA

　　Unit of Measure:PCS

　　FUKUDA Nickel Cadmium Battery

FUKUDA BATTERY

　　FUKUDA Nickel Cadmium Battery is one of the most reliable power back-up systems available in the market today.It has the unique feature of quality,safety,long life,low maintenance,reduce cost and safeguarding the environment.

　　FUKUDA KAP SERIES Nickel Cadmium Battery works by an electrochemical reaction between a Nickel positive plate and a Cadmium negative plate,immersed in a liquid alkaline electrolyte(potassium hydroxide).This reaction produces a nominal voltage of 1.2 volts per cell.Required voltages are obtained by connecting these cells together in series to form a battery.

　　FUKUDA KAP series batteries cell full comply with the requirement of the IEC 60623 and tested by Intertek International,SIRIM QAS.

　　Switchgear Tripping

　　MRT/LRT Railway

　　UPS

　　DC Instrumentation

　　Water Treatment Plant

　　Commercial/Industrial Buildings

　　CAPACITY RANGE

　　From 10AH to 1000AH

　　FUKUDA NICKEL CADMIUM BATTERY SPECIFICATION

　　Brand‘FUKUDA‘

　　Model KAP Series

　　Type Pocket Plate Nickel Cadmium

　　Standard compliance IEC 60623

　　Positive plate construction Nickel

　　Negative plate construction Cadmium

　　Nominal voltage per cell 1.2V

　　Float charge per cell 1.4 to 1.42 volt per cell

　　High rate(boost)per cell 1.55 to 1.65 volt per cell

　　Type of electrolyte Potassium Hydroxide

　　Specific gravity 1.20+/-0.01

　　Weight per cell Refer to product catalog

　　Dimension per cell Refer to product catalog

　　Battery container Translucent polypropylene

　　Battery designed life 10-15 years,under float charged standby condition

　　Accessories Included
