Features

UV-Enhanced Aluminum Coating for 250 - 450 nm

Four Diameter Options: 1/2", 1", 2", or 75 mm

Focal Lengths Range from 9.5 mm - 1000 mm

UV-Enhanced Aluminum-Coated Concave Mirrors are designed for light collection, imaging, and focusing applications. These reflective optics focus light without chromatic aberration, making them especially suitable for broadband sources.

These mirrors offer >90% average reflection in the ultraviolet spectral range from 250 - 450 nm. They consist of an N-BK7 substrate with a UV-enhanced protected aluminum coating. With low surface irregularity at 633 nm, these mirrors provide excellent image quality.
