Used for screen printing on glass and ceramic surfaces, sintered resin for high-temperature tempering and sintering ink

Functional resin for water-based high-temperature sintering connectors. High thixotropy and adhesion, suitable for high-temperature sintering inks with high load-bearing systems.
Paired with AH1050B, the rheological properties, load-bearing capacity, dryness, and other properties of the formula system can be more flexibly adjusted. The data provided on this data page are only typical numerical values and not technical indicators of the product.
Solid content: (± 2%) 50
Appearance: yellowish transparent to microemulsion liquid
Solvent: Alcoholic ether
Viscosity: (cps/25 ℃) 3000~6000
Product Features
Suitable for high load bearing, high powder to oil ratio high-temperature sintering ink
• Good adhesion
Good wetting and dispersibility
• Excellent color display performance
• Tactile and anti sinking properties
• Low odor
• No residue or trace left during roasting
Application Direction
Water based high-temperature tempered glass sintering ink
• Electronic paste
Thick film paste
Ceramic slurry
solubility
Soluble in solvents such as water, alcohols, and ethers, please test the stability of the resin in the solvent and the effect of the solvent on its properties before use. Reference formula
Reference formula for high-temperature sintering ink blending oil:
AH1050A：28
AH1050B：12
Diethylene glycol butyl ether: 40
Diethylene glycol methyl ether: 19.4
Dispersant: 0.5
Defoamer: 0.1
Total: 100.0
Reference formula for high-temperature sintering ink:
Ink blending oil: 11-18
Glaze material: 89~82
