Product Description

Urapivot is our Brand for Center pivots. Made in Spain.

Center pivot and lateral move irrigation systems composed of self-propelled structures equipped with sprinkler irrigation and control elements which make it possible to irrigate large surfaces with low installation and maintained costs.

Center Pivot

Is a form of overhead sprinkler irrigation consisting of several segments of pipes of galvanized steel joined together and supported by trusses, mounted on wheeled towers with sprinklers positioned along its length.

The machine moves in a circular pattern and is fed with water from the pivot point at the center of the circle. This system makes it possible to irrigate large surfaces with low installation and maintained costs.

A circular area centered on the pivot is irrigated, often creating a circular pattern in crops when viewed from above.

For further information, don't hesitate to Contact us

Range Of Center Pivot Models

Area	Pipe	Model	Span length	Height over ground	Tyres
Up to 45 ha	5"	URA5	41 to 59m	3.1m	14.9x24
Up to 85 ha	6 5/8"	URA6	34 to 61m	2.20-4.22m	14.9x24	16.9x25
Up to 150 ha	8"	URA8	30 to 54m	2.87-4.52m	14.9x24	16.9x25

Specification

Type	Center Pivot Irrigation System
Place of Origin	Spain
Manufacturer	Grupo Chamartin S.A.
Use	Watering and Irrigation
Application	Agricluture Farm Machine
Brand Name	Urapivot
Model Number	URA5, URA6, URA8
Feature	Energy saving, water saving
Min. Order Quantity	1 Set/Sets
FOB Price	EUR 19000~/ Unit
Port	Valencia
Payment Terms	L/C T/T
Production Capacity	40 Set/Sets / Month
Packaging Details	Standard pallets in container
Delivery Time	1 months
