promotion !!!Poultry farming equipment poultry feed chicken feed automatic

Size Width	3M per line
Feed pan	PP
Capacity(Meter)	10-12pcs chicks per meter
LifeTime	UP 10 years
Use	For Automatic Chickens/Ducks
Advantages	Automatic equipment/ Saving Labor
	Automatic operated for chicken,broiler and duck
	Suitable for different days chicken.
	Easier to install and clean
	Increasing chicken living rate.

Automatic feeder for chicken

Drving motor

Power: 0.75Kw/1.1Kw/1.5Kw,

Voltage:380V/220V/others Three-phase/Single-phase

Frequency:50Hz/60Hz, AC current

Pan feeding lines

Feed pipe:

Diameter of feed pipe:Φ45mm

Material:hot-dip galvanized sheet pipe with the zinc coating amount

>275m2.

Helical spring auger is imported from South Africa, feeding ability:

400Kg/h

Feed pan:

Feeding line specification: 4 feed pans/3m, 3 feed pans/3m

Capability: 50-55 broilers/feed pan

Feeder Pan: Diameter of plastic pan:360mm, 14 Grids

Feeder Pipe: Hot galvanizes pipe's diameter:45mm, 4 holes/3m or 3 holes/ 3m

Hopper: Container volume 120L,V hopper.

Driving Motor: motor driver 750w,380v, transmission speed 450kg/h.

Specifications

Made of high quality raw material
Easy installation and disassembly
Easy cleaning and disinfecting

Automatic chicken feeding equipment consists of a driving motor, a hopper, a conveying pipe, auger feed pans, a suspension lifting device and an anti-perching device and a feed sensor. The main function of the system is to deliver the feed in the hopper into each tray to ensure the eating of meat chickens and automatical control the conveying opening and closing of the motor by a feed sensor to achieve the aim of automatic feeding.

Adjustable feeding system ,This pan feeding system make it easy for birds to access to the feed and reduce feed waste.
This pan feeding system is easy to install and clean,long life span.
The height of edge is moderate, the brood from day one can eat.
Continuous auger deliver the feed up, down and round the corner(the auger is our own product with no welding joint)

Farm from custumer

company introduction

Qinbao enterprise limited was established in 1998 ,

we are manufactures that engaged in animal

husbandry machinery and provide users

with a full range of breeding facilities.

We have do this for 17 years and export our product

to many countries like Australia , Nigeria and etc .

shipping and packing

we pack all of our product in export standard to protect the goods ,

we can also pack as client's requirment .

we can only provide you the goods if you have your own forwarder .

If you need us to ship and find forwarder for you ,we also have rich experience on it .

FAQ.

1. How to Make an Order?

You can Order on line by Alibaba, Or Contact our Sales, and our People will contact you immediately and help you proceed with the Orders.

2.Where is Your Factory?

Our Factory is Located in Hebei province which is A Famous City for Producing farming equipment .

3. Do you give Special Discounts to the Wholesaler or we make big Quantity?

Yes we will according to your Quantity and give you the Best Support. Normally we making the EXW Price at the First Moment, but if you can order more than a Container Quantity, we will provide the Best FOB Price.

4.What is your Delivery Time?

We Normally have most of the product in stocks, please contact us when you have any questions , your any inquiries are highly appreciated .

5. Can you Arrange the Shipment Door to Door?

To better help Customer, We Can Not Only Provide the Air Shipping door to Door and Also Sea Shipping Door to Door Service, Which Can Save the Buyer a Lot of Energy and money. We have our Cooperate Forwarder in Foreign Country and will arrange the Custom Clearance Job For you.

6.What’s your Warranty?

We normally will Provide One To Two Year Warranty according to Different Products. When Products Happen Quality Problem and which is Caused by the Supplier or Facotry Producing Mistake, We will giving Free Replacement for the Customers. If it Were damage during the Shipping Or other Reasons, The Seller will Communicated with the buyer and provide the Best Solution for Making the customer Happy.

7.What Payment You Accepted?

We Normally will provide the TT, WESTERN UNION to Arrange the Payment. If the have special Remarks, you can contact and Communicate with our Sales for Better support!
