Specifications

Plastic Cable Electrical Wire PVC Wiring Channel

1.Material:PVC

2.Thickness:0.40mm~2.0mm

3.Standard:EN/13245-2/2005

                      Plastic Cable Electrical Wire PVC Wiring Channel







1. Product Description



Impact strength	Resistant to compression and impact, suitable to be buried in concrete
Non-conductive	Good insulation, able to resist 25KV voltage, assuring a safe system
Fire resistance	with self-extinguishing function
Corrosion Resistance	Resistant to acids, bases and salts, assuring a lower maintenance cost and a longer performance life
Smooth surface	Small friction and high flow capacity to ensure the cables go through smoothly
Easy Installation	Light weight, easy to cut, transport, bent and handle; easy connecting by solvent cement and threading joining without leakage







2. Trunking Specification and Custom Size Accepted



Item	Size(W*H)mm	Thickness(mm)
PVC Trunking	10x10	0.60
	15x10	0.55/0.80
	16x16	0.58/0.63/0.80/1.00
	18x9	0.40
	20x10	0.45/0.55/0.70
	20x12	0.50/0.60/0.80
	23x13	0.65/0.75
	24x14	0.65/0.7
	25x16	0.63/0.72/1.00
	25x25	0.75/0.95
	30x15	0.60/0.76
	39x19	0.75/0.90
	40x16	0.60/0.80/1.00
	40x25	0.68/0.76/1.00/1.20
	40x30	1.00/1.20
	40x40	1.38
	50x25	1.00
PVC  Square Trunking	50x50	1.10/1.25
	59x22	0.85/1.10
	60x30	1.10
	60x40	1.20/1.40
	60x60	1.68
	75x50	1.25
	75x75	1.30/1.50
	80x40	1.35
	80x50	1.40/1.70
	99x27	0.90/1.20
	100x40	1.35/1.50
	100x50	1.35/1.70
	100x60	1.65/1.90
	100x75	1.65/2.00
	100x100	1.60/2.00
	100x150	2.00
PVC ARC-Floor Trunking	35x10	1.75
	50x15	1.60
	70x20	2.00
Special PVC Trunking	100x50	1.35 (three spacers)
	100x50	1.35 (four spacers)
Customized	Accepted





3. Our Advantage



1) Machinery: More than 60 advanced Extrusion machine and 30 Injection

machine with max 500T.

2) Experience: Over 30 years of experience in Thermoplastic Extrusion and Injection, such as running temperature control and continuously formula optimization.



3)Quality Assurance: 24-hour Rigorous QC Team which is in line with ISO 9001 Certification;

Large-scaled Mould Workshop: with 4 senior mould designers and a team of experienced mould manufacturing technicians.



4)International Projects: Supply building and irrigation Projects in Asia, Africa, Middle East, Russia and other countries .





Product Showing







Our Factory







Our Certification
