Drip Irrigation Pipe Extruder With Flat Dripper

Flat emitter  drip Irrigation Pipe machinery

High-speed automated screening and embedding system
With slight adjustment,the screening and embedding system then can be used foridentification and transportation for single-hole dripper,middle-hole dripper and double-hole dripper.
The system has special designed identification device that can provide 100% dripper passing guarantee.
Identification speed>600pcs/min.
Dripper embedded space:between 150-1500mm,the dripping hole space can be adjusted through the PLC interface.
Automatic punching technology and online monitoring system
Own National invention patent(National Patent No:ZL200710063376.7)
High-speed for punching single hole,middle hole and double hole.Speed>500 times/min.
Configured with two alarm system for addident skipping and spacing deviation identify.
Configured with high-speed camera and PLC interface operating interface for tracking,monitoring and record storage.

Automatic rewinding and metering functionality
It is used by servo motor drive.
Automatic completion for dripper winding displacement,cutting and metering.
Very simple PLC operating interface for winding speed and roll volume control.





Item	Pipe diameter	Pipe thickness	Production speed	Distance of dripper
Flat dripper irrigation pipe production line	Φ12-16-20mm	0.15-1.0mm	100-150m/min	100150200300400500-1500mm





 FACTORY PLANT:





 EXHIBTION INFORMATION:
