5XDC-3 Belt Cleaning machine

Brief Introduction:

This machine applied to the seed which after the primaries selecting . The use of the seeds difference of friction coefficient for sorting.

The range for selecting seeds:

1-      Selecting beans from the broken beans and irregular particles;

2-      Selecting red clover seed from the herbal plantain’s seds;

3-      Selecting oat seeds from the Vicia villosa;

4-      Selecting Sage from the ryegrass and carrion flower;

Selecting beet seed from the stem and stalk. Etc.

Technical specification



Model	5XDC-3	5XDC-4
Productivity	2000-3000 kg/h	3000-4000 kg/h
Size               (length*width*height  )	4100×2000×3300 mm	4200×2000×3500 mm
Belt area size(Length*Width)	2000*1000 mm×6	2000*1000 mm×8
Reducer power	380V / 50Hz / 3kW	380V / 50Hz / 4kW
Reducer rotational speed	40-200Rpm	40-200Rpm
Weight	1300 kg	1450 kg
Auto cleaning rate	≥ 96%	≥ 96%
Movable speed	≤ 10 km/h	≤ 10 km/h
