5XDC-3 cocoa bean cleaning machine

Product description


Product Description




Specifications



5XDC-3 cocoa bean cleaning machine

Minimum order quantity:1set

Delivery time: 20days

Payment term: T/T or L/C



5XDC-3   cocoa bean cleaning machine



Brief Introduction:

This machine applied to the seed which after the primaries selecting . The use of the seeds difference of friction coefficient for sorting.

The range for selecting seeds:

1-     Selecting beans from the broken beans and irregular particles;

2-     Selecting red clover seed from the herba plantaginis seeds;

3-     Selecting oat seeds from the Vicia villosa;

4-     Selecting Sage from the ryegrass and carrion flower;

5-     Selecting beet seed from the stem and stalk. Etc.



Main performance indicators and technical parameters

Model

5XDC-3

Productivity

3000-5000 kg/h

Size length*width*height

3383*1954*3044 mm

Belt area size(Length*Width)

4100*1000 mm

Reducer power

380V / 50Hz / 2.2Kw

Reducer rotational speed

40-200

Weight

950 kg

Auto cleaning rate

≥ 96%

Movable speed

≤ 10 km/h






















5XDC-3 cocoa bean cleaning machine
