concertina wire



Razor barbed tape is a kind of modern security fencing materials fabricated with razor-sharp steel blade and high-tensile wire.



Razor Wire Variety: Concertina Coils Type ;Straight Type Razor Wire



Surface treatment:  Hot dipped galvanzied razor wire mesh , electric galvanzied wire , PVC wire mesh , or SS razor wire mesh.



Technical Info of PVC Coated Barbed Iron Wire:

• Core of PVC Coated Barbed Iron Wire can be galvanized iron wire or black annealed iron wire.
• A variety of colors like green, blue, yellow, orange, gray, is available with PVC Coated Barbed Iron Wire produced by us.
• Tensile strength of Standard PVC Coated Barbed Iron Wire is 30-45 kgs./sq.mm.
• Packing: In coil of 25 kilos or 50 kilos net, lined with P.V.C strips, then wrapped with P.V.C or hessian cloth.

Reference Number	Blade Style	Thickness	Wire Dia	Barb Length	Barb Width	Barb spacing
BTO-10		0.5±0.05	2.5±0.1	10±1	13±1	26±1
BTO-15		0.5±0.05	2.5±0.1	15±1	15±1	33±1
BTO-22		0.5±0.05	2.5±0.1	22±1	15±1	34±1
CBT-65		0.6±0.05	2.5±0.1	65±2	21±1	100±2



Barbed Tape Wire Specification:



Outside Diameter	No. of Loops	Standard Length per Coil	Type	Notes
450mm	33	8M	CBT-65	Single coil
500mm	41	10M	CBT-65	Single coil
700mm	41	10M	CBT-65	Single coil
960mm	53	13M	CBT-65	Single coil
500mm	102	16M	BTO-10.15.22	Cross type
600mm	86	14M	BTO-10.15.22	Cross type
700mm	72	12M	BTO-10.15.22	Cross type
800mm	64	10M	BTO-10.15.22	Cross type
960mm	52	9M	BTO-10.15.22	Cross type
