Specifications

1kw-10kw alternator generator

100% copper wire

CE&EPA

50hz ,60hz

with wheel kits

Features of our portable gasoline generators:

 OHV Air-Cooled Engine
•Splash lubrication provides longer engine life

Large Capacity Fuel Tank with Fuel Gauge
•Lets the operator know current fuel level

Two-Wheel Kit
•Provides enhanced portability and convenience

Hardened Steel Tube Cradle
•Protects the generator from damage

Low Tone Muffler
•Provides quiet operation

Covered Outlets
•Provides added safety and extends the life of the generator



Packing&Delivery Days

*Packing: Chima Packing/ Netural Packing /Customer's Packing



*Delivery Days:15-20days after Deposit received



 Service&Quality Control



*We are manufacturer , professional enough to provide good service&quality control.



*Inquiry Is welcome.Technology support is available from us.





Specifications:

	Model No.	WY2.5GF-3/2.5GF-4	WY2.8GF-3/2.8GF-4	WY3GF-3/3GF-4
Generator	Noise(7meters away)	70db	71db	69db
	Rated output frequency	50hz	50hz	50hz
	Rated output voltage	220v	220v	220v
	Rated ouput power	2.50kw	2.80kw	3.0kw
	Max Output Power	2.7kw	3.0kw	3.3kw
Gasoline Engine	Engine Model	168FB/168F-2D	170F/170FD	173F/173FD
	Engine type	4-stroke ,25″ inclinded single -clinder,air-cooled
	BorexStroke (mm)	68x54	70x56	73x58
	Displacement(ml)	196	212	242
	Compression Ratio	8.5:1	8.5:1	8.2:1
	Theoretical Maximum Output Power	4.8kw/3600rpm	5.2kw/3600rpm	5.8kw/3600rpm
	Rated output power	3.8kw/3600rpm	4.2kw/3600rpm	5.1kw/3600rpm
	Continuouse Operating	10.3hr	9.3hr	13hr
	Horse Power	6.5Hp	7.0hp	8Hp
	Max Torque	11N.m/3000rpm	11.5N.m/3000rpm	14.5N.m/3000rpm
	Ignition system	Non-contact Transistorized Magneto(TCL)
	Start System	Recoil Start /Electric Start
	Air Cleaner	Semi-dry type /Oil bath type
	Fuel Tank Capacity	15L	15L	25L
	Fuel Consumption	1.45L/h	1.6L/h	1.9L/hr
	Oil Capacity	0.6L	0.6L	1.1L
Packing Detail	Dimension (LXWXH)mm	610x460x470	610x460x470	735x555x580
	Net Weight	47/49KG	48/50KG	65KG























Features of our portable gasoline generators:

 OHV Air-Cooled Engine
•Splash lubrication provides longer engine life

Large Capacity Fuel Tank with Fuel Gauge
•Lets the operator know current fuel level

Two-Wheel Kit
•Provides enhanced portability and convenience

Hardened Steel Tube Cradle
•Protects the generator from damage

Low Tone Muffler
•Provides quiet operation

Covered Outlets
•Provides added safety and extends the life of the generator



Packing&Delivery Days

*Packing: Chima Packing/ Netural Packing /Customer's Packing



*Delivery Days:15-20days after Deposit received



 Service&Quality Control



*We are manufacturer , professional enough to provide good service&quality control.



*Inquiry Is welcome.Technology support is available from us



Company Introduction



We are a specialized factory to supply gasoline engines,diesel engines,gasoline tillers,diesel tillers,gasoline water pumps,diesel water pumps,gasoline Generators and grass cutters etc . Please visit our websites at







www.              http://cqweiyou.en.china.cn/
Why you should choose us :
1.10 years of manufacturing expenrience in the field of general machineries
2.Professional engineers and test equipments to ensure the quality of each machine
3. Factory direct selling at competitive prices
4. OEM service is available
5. Fast and efficient delivery service
6. Strictly quality control system







COMPANY INTRODUCTION :
Chongqing Winyou Power Co,.Ltd is one of the leading professional manufacturer of general machineris including engines(gas and diesel),power tillers (gas/diesel),water pumps(gas/diesel),generaters and grass cutters as well as other agricultural machines. Our products sell well in 30 countries of the world,including America,Europ,Africa,Midle East,Southeast Asia etc,enjoy a good reputation domestic and overseas .
