Sunshade FOTON europard Tractor FT604, 60HP 4x4, fit with 4in1 Front end loader

Product description

Product Description

1.Foton tractor 25-120HP

2.Double valve,luxury chair

3.Dual stage cluth,Shuttle gear

4.TZ04D 4in1 loader with teeth

5.Rops

Technical Data Collection List of the Front Loader

	Model	TZ02	TZ02D	TZ03	TZ03D	TZ04	TZ04D	TZ06	TZ06D	TZ08	TZ08D
	Tractor model	254		284/304/354		404454/504/554		604/354/704		754/804/824/904
A	Height–measured at arm pivot point	2100	2360	2400	2700	2500	2800	2700	3100	3050	3080
C	Max. dump height (mm)	1700	1800	2000	2000	2100	2100	2200	2300	2300	2350
D	Dump distance (Max. dump height) (mm)	500	600	700	800	800	900	1100	1100	1020	1100
E	Dump angle (°) (Max. dump height) (mm)	42	45	42	45	42	45	42	45	42	43
F	Distance to the centre of front-wheel (mm)	1550	1800	1800	1900	1800	1900	2000	2300	2200	2400
G	Rollback angle on ground (°)	26	32	26	32	26	32	27	34	28	34
H	Max. digging depth (mm)	100	100	100	140	100	140	110	140	160	180
	Bucket width (mm)	1250	1250	1400	1400	1500	1500	1600	1600	1700	1700
	Bucket capacity (m³)	0.18	0.18	0.21	0.21	0.23	0.23	0.43	0.43	0.46	0.46
	Rated lift capacity (Kg)	200	200	300	300	400	400	600	600	800	800

Company profile

Gooler International Group Co., Ltd.

Main products:Wood Chipper ,Front end loader ,Backhoe ,Mowers ,irrigation system
