Specifications

simple structure

easy to operate

strong and durable

Acid-Alkaline resistant

Improve the survival rate

Foaling pen(2200X1800X1100)
Name	Specification	weight	remark
Sidebar(left)	2200X1080	19.20	hot dip gavenizing,1",3/4",1/2"
Sidebar(right )	2200X1080	19.44	hot dip gavenizing,,1",3/4",1/2"
Door(left front)	520X900	6.98	hot dip gavenizing,3/4",1/2"
Door(left front)		6.98	hot dip gavenizing,3/4",1/2"
Door(left rear)	520X520	3.97	hot dip gavenizing,1/2",φ8round iron
Door(right rear)		3.97	hot dip gavenizing,1/2",φ8round iron
cabane	630X820	3.10	hot dip gavenizing,1/2"
Limited rod	690X550	3.65	hot dip gavenizing,3/4",1/2"
locating bar	454X545	3.45	hot dip gavenizing,1/2",φ8round iron
locating bar		3.45	hot dip gavenizing,1/2"φ8round iron
locating bar	1398X520	6.45	hot dip gavenizing,1/2"φ8round iron
locating bar	918X520	6.02	hot dip gavenizing,1/2",φ8round iron
Fences	2137X520	12.96	hot dip gavenizing,1/2",φ8round iron
Limited  Pipe	2210	2.06	galvanized pipe,1/2"
Girder	2200	5.14	60X5steel flat
Bolt	M10×30	0.03	standard parts
Nut	M10	0.01	standard parts
Gasket	10	0.00	standard parts
Bolt	M10×60	0.06	standard parts
Nut	M10	0.01	standard parts
Gasket	10	0.00	standard parts
Bolt	M6×60	0.01	standard parts
Nut	M6	0.00	standard parts
Gasket	6	0.00	standard parts
Bolt	M10×25	0.03	standard parts
Nut	M10	0.01	standard parts
Gasket	10	0.00	standard parts
warm-box	1100X600X700	11.00	glass fiber reinforced plastics
crib(sow)	400X310X420	19.00	HT200
crib(baby pig)	Φ335x235	8.50	HT200
foot	130mmheight	1.48	HT200
foot	150mmheight	1.65	HT200
crossbeam	2200	9.00	QT400
crossbeam	1425	5.80	QT400
crossbeam	945	3.20	QT400
floor(sow)	550X600X30	12.30	QT400
floor(baby pig)	550X480X70	2.20	plastic



cast iron feeder



aluminium alloy feeder

fiberglass box for warming piglet

 Farrowing crate for tow sows is including as follows:



Two plastic piglets feeders , two cast-iron feeders for sow , two fiberglass boxes, cast-iron support Bars , hot-dip galvanized steels , cast-Iron slat floor for sows , plastic slat floor for piglets

2200*1800*1100(only for one sows)
