Specifications

Automatic Ice Block Machine

1.daily capacity:10000kgs

ntainerized design

3.automatically dropping ice

4.edible ice block

TV Series Automatic Ice Block Machine



Automatic Ice Block Machine Models:



Item No.	Production	Compressor Rated Power	Water Pump Power	Machine Dimension
	Ton/24H	KW	KW	L*W*H
ABI 10	1.0	3.92	0.37	1100*1400*1850
ABI 20	2.0	7.11	0.37	1200*1400*2300
ABI 30	3.0	9.66	0.55	1100*1700*2000
ABI 50	5.0	14.6	0.55	1500*1500*3500
ABI 80	8.0	21.9	1.10	1500*2000*3000
ABI 100	10.0	27.0	1.10	1500*2000*3500
ABI 125	12.5	38.0	1.50	1500*2000*4000
ABI 150	15.0	50.4	2.25	1500*2000*6000
ABI 200	20.0	65.8	3.00	1500*2000*7000





































Machine running condition: water temperature 16°C, evaporate temperature -12°C,condensing temperature 40°C, reference valve under 50Hz power condition. Real production of machine will have a little change according to change of water temperature and ambient temperature.



Edible Ice Block Features:



1. Under the circumstance of the supply water reached the drink standard, then, the ice blocks completely can reach the edible request.
2. The ice-making evaporator material is the stainless steel 304(SUS304) or Aluminium, clean and sanitary; stable refrigerant efficiency, the life for the refrigerant evaporator can beyond 30years and still keep the same shape as before. So it not exist the replace or repair problem.
3. The ice machine can be make into the containerized type or module type, easy operate, and saving space.
4. When after the ice formed, it will dropping into the special ice contact convey device from the ice models, it no need crane and other hoist equipment, reduced the operating cost and usage space.
