21.5\" HDMI Digital Industrial LCD touchscreen Monitor IR Waterproof panel

Product description


Product Description




Delivery Time:7 working days
Certification:CE/FCC/ROHS/CCC

21.5\" HDMI Digital Industrial LCD touchscreen Monitor IR Waterproof panel


Infrared  touch screen of 21.5 inch industrial LED open frame monitor with VGA HDMI input; slim and thin design for 21.5’’ touch  LCD. Full HD with low consumption widely used for Automatic industry , All in one equipments, Advertising , vending embedded system, Kiosks, etc


Quick Details:













Model: AXD-21OPN1P2-T4



Screen Size:21.5’’



Screen format: 16:9



Display Resolution(pixel):1920X1080



Contrast Ratio:1000:1



Brightness:250cd/m^2



Storage temperature : -10℃~70℃



Input signal: VGA HDMI AUDIO



Power Input: AC100~240 V/DC 12V


Touch Type: IR multi- touch



Product status: Stock



Features and Advantages



1. New and Industrial A grade perfect panels with stable supply

2. Slim and simple open frame to mount all the LCD kits in one , which is easily installed

3. industrial control board supports the displays working 24 hours

4. Professional and industrial hardware and parts to guarantee its working normally in rough environment

5. VGA DVI interfaces ;USB Touch screen

6. 21.5 inch open frame touch LCD for application control , advertising player ,campus and industrial terminals etc



















































Display Specifications




Display



21.5\" Touch LCD Open frame



Model Name



AXD-21OPN1P2-T4



Active Display Area (mm)



476.64 (H)x268.11(V)



Pixel Pitch (mm)



0.282(H)x0.282(V)



Resolution (Pixel)



WSXGA (1920X1080)



Brightness (CD/m^2)



250cd/m^2



Contrast Ratio



1000:1



Viewing Angle (CR >=10)



160/160



Power consumption



17.6 W typical, low consumption ,normal operation



Touch Screen



Resistive RS232/USB(Optional)



OSD Control



On the back side



I/O Connectors



1x12v,1XVGA,HDMI, Audio



Power Input



DC 12V,4A 48W



Mechanical Specifications




Construction



Steel metal housing



Dimensions



522.0x 294.6x 33.0(mm)



Mounting



Embedded ,fixing holes on the back frame



Power source



AC 100~240V/ 12V DC



Environment Specifications




Operating Temperature



-10~60℃



Storage Temperature



-20~60℃



Rating



Facilitate installation of the demolition,solid portfolio



Ordering Information



21.5” Touch lcd Open frame FHD with HDMI input with speaker



Packaging & Delivery








Packing details



1x 21.5  inch Industrial Touch Screen Monitor;


Packed in 5 pieces/carton with protection foam


Optional accessories: 1xVGA, 1x Power supply cable, 1x power


adapter



Delivery terms



7- working days for stock products after receiving payments;  15 working days for order production
