Delivery Time:7-20 workdays
Certification:CE, ROHS,CCC

Australian Plug Tabletop Interconnect Box With Rj11 Network

Quick Detail:

Flush-mount tilt up cable connection box,desktop outlet, tabletop outlet, pop up socket

-Open/close by pressing on top panel

-With Power, RJ45 or RJ11

-Easy assemble and convenient for user

-Tabletop Socket

Description:

JS-553+ interconnect box provides inconspicuous access for one three-pin power supply, two VGA and, and four network( or two network, two telephone).

The interconnect box is a compact interconnect solution designed for installation into a table as part of a presentation system. It can be mounted into a table, podium and stage to provide a way to connecting audio visual equipment on top of furniture to a presentation system under the furniture.

Open and close:

There is a pneumatic spring inside the box. Press on the centerpiece of the lid until the latch audibly disengages. Releases and the lid will pop open, showing the available connections.

Press down on the centre of the lid until the latch audibly engages. Release and the lid will be closed.

Picture:

Power Options:

Top panel options:

Applications:

The interconnect box is ideal for office, boardrooms, classrooms, hotel rooms and large training facilities where multiple, distributed tabletop cable connections are needed.

Specifications:

JS-553+ main Specification
Ports	2x 3 pin AC power Female-IEC plug
4x RJ45 F-F
Weight	N.W.: 2kg, G.W.: 2.4 kg
Panel size	193x150 mm, R=16.5mm
Cutout size	183x140mm, R=12mm
Table thickness	≤60mm
Operating Temperature	0~40 ℃
Warranty	1 year
Certificate	CE, RoHS, CCC

Competitive Advantage:

1. Very good processing and treatment give it a perfect appearance

2. With high quality connectors and parts stand for long time service

3. Easy to assemble and convenient for user

4. Customizable
