BM-CNC3K22 brush drilling machine for besom brushes
Product description
Product Description
Specifications
BM-CNC3K22 is a 3 axis brush drilling machine
1)drill kinds of different material brushes
2)store 2000 programmes
3)ISO CE
BM-CNC3K22 brush drilling machine plastic handles:
BM-CNC3K22 3 Axes Drilling Machine Description
| Item | Model | BM-CNC3K22 |
| 1 | NO. of axis | 3-axis |
| 2 | The stroke of X axis | 200mm rovide flexible customize for customer. |
| The stroke of Y axis | 150mm rovide flexible customize for customer. | |
| The swing angle of Z axis | 360° | |
| 3 | Setting of Worktable | high-precision straight-line rail and ball screw,steady and durable. |
| 4 | Material of Brush Handle | Polyethylene, polystyrene, return materials, wood |
| 5 | Application | To drill varieties of disc brushes |
| 6 | Depth of hole | 1-12mm |
| 7 | Diameter of hole | 2mm-4mm |
| 8 | Maximum Drilling Speed | 6 holes/second |
| 9 | Max Speed | 15000n/min |
| 10 | High Speed Motor | Italian High-Speed Motor |
| 11 | AC motor | Italian Brake Motor |
| 12 | Type&Brand of Driver/Motor | stepper motor by default , can adopt some brand motor&driver requested by users. |
| 13 | Adjust Speed | Frequency-conversion stepless-adjustable speed |
| 14 | Replaceable Fixture | FMS type. It can be easily changed to make other kinds of brushes. |
| 15 | Programme Storage | Store 2000 programme,each can imput 100 thousand processing data. |
| 16 | Program System | CNC system,high precision,stability and efficiency |
| 17 | Dimension(L*W*H) | 1000×600×1600mm |
| 18 | Gross weight | 400KG |
| 19 | Power | 3-phase 380v, 50Hz |
| 20 | Total power | About 800w |
| 21 | Compressed Air Pressure | 0.6-0.8Mpa |
BM-CNC3K22 3 Axes Brush Drilling Machine Feature
| 1 | With 5.7 LCD screen,Chinese and English interface. | |
| 2 | Supports data switching.The controller can be used as a U-Disk,and it also can be connected with U-Disk. | |
| 3 | Convenient to adjust the hole position with the handwheel. | |
| 4 | Long life , nice feel,and reliable keypad. | |
| 5 | Safe to operate.With alarming fuction ,the system will give an alam and stop to run when the machine fails. | |
| 6 | Full Featured, Editing functions of processing data, such as ADD, ALT,INSERT,DELETE, makes it convenient to solve these problems: the deviation of hole position, hole-repeating and hole-missing. | |
| 7 | Easy to operate and program. | |
| 8 | Large capacity,it can store 2000 programmes and each programme can imput 100,000 processing data. | |
| 9 | Convenient to find the specific program by choosing the program number. | |
| 10 | Standard designed circuit reduces the line interference and makes sure send the correct singal. | |
| 11 | You can confirm whether the hole postion is right by step test after the program is saved. | |
| 12 | Reasonable designed mechanical part position makes the machine good features. | |
| 13 | Standard spare parts offered. | |
| 14 | Spare parts are all made by our factory.It is very easy to replaceable. | |
