The swirl impeller is all or part of the impeller is retracted to the flow channel of the pressure chamber, and has good anti-clogging performance. The particles flow in the water pressure chamber is driven by the eddy current generated by the rotation of the impeller. The movement of the suspended particles does not generate energy, and the flow channel exchanges energy with the liquid. In the flow process, suspended particles or long fibers do not contact with the worn blades, and the blades are slightly worn, and there is no increase in clearance due to abrasion, which is suitable for pumping media containing large particles and long fibers.

The open impeller has only blades and blade stiffeners, and no front and rear cover plates. The number of open impeller blades is less than 2-5. The pump impeller has low efficiency and less application. It is mainly used to transport liquid with high viscosity and slurry liquid.

The runner impeller is a curved flow channel from the inlet to the outlet. This type of impeller is suitable for conveying liquid containing large particle impurities or long fibers. Because this type of impeller has excellent anti-clogging performance. But its disadvantage is that its cavitation resistance is weaker than other forms.
