Brand

Innolux

Model P/N

G150XNE-L01

Diagonal Size

15.0"

Panel Type

a-Si TFT-LCD, LCM

Resolution

1024(RGB)×768, XGA  85PPI

Pixel Format

RGB Vertical Stripe

Active Area

304.128(W)×228.096(H) mm

Bezel Opening

307.4(W)×231.3(H) mm

Outline(mm)

326.5 × 253.5 × 9.6 (H×V×D)

Treatment

Antiglare, Hard coating (3H)

Luminance

500 cd/m² (Typ.)

Contrast Ratio

2500 : 1 (Typ.) (TM)

Viewing Angle

88/88/88/88 (Typ.)(CR≥10)

Response

13/5 (Typ.)(Tr/Td) ms

Good View at

Symmetry

Work Mode

NPVA, Normally Black, Transmissive

Color Depth

262K/16.7M   72% NTSC

Backlight

WLED , 70K hours , With LED Driver

Mass

0.97/1.00Kgs (Typ./Max.)

Used for

Refresh Rate

60Hz

Touchscreen

Without

Signal Type

LVDS (1 ch, 6/8-bit) , 20 pins Connector

Voltage Supply

3.3V (Typ.)

Max. Ratings

Storage Temp.: -40 ~ 85 °C    Operating Temp.: -30 ~ 80 °C
