Lastest model hydrogen sulfide detector detector and alarm with high quality
Product description
Product Description
fixed hydrogen sulfide detector
fixed butane detector
explosive gas detection alarm
Brief Introduction
TGas-1031 Series Combustible, Toxic and Harmful Gas Transmitter can continuously measure the concentration of site gas, and convert the concentration signal into 4-20mA output. It is extensively applied in petroleum, petrochemistry, chemical industry, gas, coal, metallurgy and electric power; safety detection in municipal administration, telecommunication and traffic tunnel construction; the place where combustible, poisonous and harmful gas might leak, such as gasholder station and special industrial factory building, etc.
The instrument adopts advanced 16-bit microcontroller with extra low power consumption and quick processing speed. It is firm and durable with the anti-skid design of shell. It is widely used in petroleum, petrochemistry, chemical industry, gas, coal, metallurgy and power system; safety detection in municipal administration, communication and traffic tunnel construction; electronics and semiconductor industry and other places where toxic and harmful gases exist.
Main features
| ExdIICT5,IP66,Explosion-proof Patent shell | Two kinds of optional mode of power supply, including centralized busbar type and independent area type
| High and low concentration alarm,real-time monitoring
| Anti-poisoning type gas sensor with high sensitivity
| Automatic modification of ageing curve of sensor, keeping constant alarm sensitivity
| Function of automatic recognition of sensor trouble, function of high concentration gas above-norm of sensor
| Automatic detection when starting up,with the function of self-diagnosis and self-reparing.
| The calibrated concentration value is adjustable, facilitating users to set by themselves
| Before the sensor loses the function of monitoring alarm because of ageing, the detector is capable of automatic recognition and alarm, so it can effectively avoid missing report.
| High and low concentration alarm,real-time monitoring
| Anti-poisoning type gas sensor with high sensitivity
| Automatic modification of ageing curve of sensor, keeping constant alarm sensitivity
| Function of automatic recognition of sensor trouble, function of high concentration gas above-norm of sensor
| Automatic detection when starting up,with the function of self-diagnosis and self-reparing.
| The calibrated concentration value is adjustable, facilitating users to set by themselves
| Before the sensor loses the function of monitoring alarm because of ageing, the detector is capable of automatic recognition and alarm, so it can effectively avoid missing report.
| Parameters | Characteristics |
| Detected Gas | chlorine |
| Sampling Method | Diffusion, Pump sampling |
| Measurement Principle | Electrochemical cell,catalytic combustion |
| Response Time | <30s |
| Detection Error | ±5%F.S |
| Operation Mode | chlorine=0-10ppm |
| Display Mode | 5-digit 8-segment LCD display |
| Working Temperature | -30~60°C |
| Environment Humidity | 0~90%RH (without condensation) |
| Storage Temperature | 0~40°C |
| Power Supply | 24VDC±25%; power: 2W/way |
| Battery | NO BATTERY SUPPORT |
| Dimension | Host machine 125mm X 153mm X 110mm REMOTE 35mm X 80mm X 28mm |
| Weight | 2KG |
| Certification of Explosion Protection | Explosion-proof grade: ExdIICT5 Protection class: IP66 |
| Calibration Mode | Select calibration cap, thus facilitate users for its calibration. |
