Feature

Advanced optical system, ensure accurate result and good repeatability.

8 channel optical fiber system enables 5 second reading for the whole plate.

Bichromatic measurement, multi-calculation methods include ABS, Cut-off, Linearity and Log.

Easily programmable and operate through PC software or keyboard

Ability to communicate with PC,free PC operating software.

Plate shaking feature



To carry out ideal operation and data management for Elisa test, we provide an intelligent PC software for AJ-1106. Working base on Windows system. Control machine, test programming, calculating results and indicating reagent recession curve. Multi-calculation methods on board: linearity, LogX, logY, logXY, Parabola regression, Polynomial regression, 4PL Regression. A complete data administration system for: micro-plate, reagent, patient, laboratory and results.



Specification

Reading Speed: 5 seconds for 96 well plate

Light source: Halogen lamp 8V/50W

Filters: 405nm, 450nm, 492nm, 630nm, 4 open positions

Photometric Range: 0.000-4.000Abs

Photometric Accuracy: ±1%(0.000-2.000Abs)

Applicable programs: 28 except of PC

Measure Mode: Monochromatic or Bichromatic

Calculation Mode: ABS; Cut-off; Linearity; LogX; LogY

Display: 240*128 LCD

Interface: RS232, parallel interface for external printer

Output: External printer (optional)
