23.6-inch circular display capacitive touch screen multi-functional irregular-shaped display query all-in-one machine
Product description
| 项目 Item | 指标 Description | ||||
| 尺寸Size | 23.6英寸/ inch | ||||
| 型号（Model NO.）:EC-DR23.6 | |||||
| 显示屏规格参数Picture/Display | 背光类型Backlight | LED | |||
| 显示分辨率Resolution | 1280x1280 | ||||
| 视角Viewing Angle | 89/89/89/89 (Typ.)(CR≥10) | ||||
| 显示颜色Display colors | 16.7M , 72% NTSC | ||||
| 亮度Brightness | 1500cd/m2 | ||||
| 对比度Contrast ratio | 1000:1 | ||||
| 响应时间Response Time | 16ms | ||||
| 有效显示面积Effective screen size | 600.384mm (H) x600.384mm (V) | ||||
| 安卓参数 | CPU | I5 | |||
| 内存 | 8GB DDR3 | ||||
| SSD | 128GB | ||||
| 操作系统 | WIN7/WIN10 | ||||
| 支网络持 | 以太网、WIFI | ||||
| 视频播放 | 支持wmv、avi、flv、rm、rmvb、mpeg 、ts、mp4 | ||||
| 图片格式 | 支持BMP、JPEG、PNG、GIF | ||||
| USB接口 | 2个USB 2.0、 | ||||
| 串口 | 3个串口插座(至少支持RS232*1) | ||||
| 以太网 | 1个RJ45，100M自适应以太网 | ||||
| HDMI输出 | 1 | ||||
| DVI | 1个 | ||||
| 喇叭Speaker | 2×8Ω 5W | ||||
| 安装方式Installation | 壁挂式 | ||||
| 机身尺寸Dimensions | 662.584x662.584x47.33mm | ||||
| 电源输入及功耗Power & Consumption | AC 110 -240V 50/60Hz 120W | ||||
| 喇叭类型 | 高保真音响 | ||||
| 喇叭最大输出功率 | 5瓦x 2 | ||||
| 音频特性 | 平衡，自动音量控制，丽音/双语环绕立体声/均衡器 | ||||
| 壁挂支架 | 壁挂 | ||||
| 输入电压 | AC 110～240V 60/50Hz | ||||
| 功耗 | ≦120W | ||||
| 省电功耗 | 低于＜1瓦 | ||||
| 整机寿命 | ＞60000小时 | ||||
