Brand: MEGAJET

Model: MJ-28045D

Pump Series: P380

Pump: Stainless Steel Crankshaft 3-plunger Pump

Pump Method: Direct connection

Internal deceleration

Working Pressure: 2800bar

Flow Rate: 45L/Min

Drive Mode: Diesel Engine

Power: 360HP

Engine: WEICHAI(China)

Water Tank: 500L

Fuel Tank: 350L

Installation Type: Container type

Net Weight: 5000KG

Machine Size: 3500*1900*2450mm

Pressure Regulating Valve: Manual and PLC adjustment selectable

Pressure Gauge: Include

Rupture Disc Holders: Two

(1) Pressure:2,800bar (40,000psi), Flow rate: 45L/min.

(2) Streamlined design, high strength plunger structure, all pressure parts are made of stainless steel, high strength, corrosion resistance, wear resistance, can effectively work under continuous high pressure.

(3) Combination valve is heat-treated stainless steel, durable.

(4) The high-pressure water seal is a low friction polymer material filled with mixed glass and carbon fiber, ensure without trace friction, no drips during movement of the plunger, the plunger cooling system can intuitively determine whether the water seal is damaged, reducing maintenance time.

(5) The crankshaft is 4143H alloy. After grinding and polishing, it is processed into the surface of neck journal bearing, sustainable operation of more than 15,000 hours at full load.

(6) Split structure of power end and hydraulic end, easy to service and maintain

(7) The product has been tested for no less than 36 hours before leaving the factory. Overflow valve for stainless steel materials, corrosion resistance, wear resistance

(8) Ultra-high pressure stuffing box, special stainless steel material after heat treatment, higher strength, stronger toughness.

(9) The flow ends structure is simple, five minutes packing change,fifteen minutes pop-out valve cartridge change,no special tools or equipment required, plunger clamped,NOT threaded.(10) This pump only needs to replace the fluid end and can be converted to 1400bar, 90L/min.

Customized: Customized
