Delivery Time:3~5

The CR501D is 13.56 MHz Contactless (RFID) Reader, it supports ISO15693 Cards type like de SLI,TI2k ,SRF55V01P,LRI2k.. base on NXP RC400 solution

Application scopes

e-Government
Banking & Payment
Access Control
Network Security
e-Purse & Loyalty
Transportation
Kiosk
Inventory system

CR501D Description

NAME	CR501D ISO15693
Weight	240g
Dimensions	110*80 *26 (mm)
Temperature	-20 － +85C
Interface	USB Virtual Rs232 / RS232
Read Range	up to 10cm
Frequency	13.56MHz
SUPPORT	ISO15693
	I.CODE SLI , Tag IT , SRF55V01P , SRF55V02P , SRF55V10P LRI2K
System	Windows XP,NT ,WIN7,WIN8 ,CS BS, Linux
SDK	W32 Win64 SDK
DEMO	VC.BC.VB.PB.DEPHI ,VB net, C# Sample source code

CR501 Serial Product Description

NAME	CR501 series Reader ISO14443A / B,ISO15693
Weight	240g
Dimensions	110*80 *26 (mm)
Temperature	-20 － +85C
Interface	USB Virtual Rs232 / RS232
Read Range	up to 10cm
Frequency	13.56MHz
SUPPORT	ISO14443A , ISO14443B , ISO15693
	Mifare 1K , Mifare 4K , Mifare Utralight , Mifare DesFire , Mifare Plus,Ultralight C , SLE66R35 , SR176 , SRIX4K , AT88RF020 , SLE66CL160S , SAMSUNG K8 , SAMSUNG V8 , I.CODE SLI , Tag IT , SRF55V01P , SRF55V02P , SRF55V10P ISO14443B contactless CPU card
System	Windows XP,NT ,WIN7,WIN8 ,CS BS, Linux
SDK	W32 Win64 SDK
DEMO	VC.BC.VB.PB.DEPHI ,VB net, C# Sample source code

CR501 Serials Part Number Description:

Model	Description	InterFace
CR501A	Mifare s50/s70,ultralight,FM1108,TYPE A	RS232
CR501AU	Mifare s50/s70,ultralight,FM1108,TYPE A	USB virtual RS232
CR501B	Mode A + AT88rf020,SR176,SR4k,TYPE B cpu	RS232
CR501BU	Mode A + AT88rf020,SR176,SR4k,TYPE B cpu	USB Vitual RS232
CR501D	ISO15693,desli, Ti2k,SRF55V01,SRF55V02,SRF55V10	RS232
CR501DU	ISO15693,desli, Ti2k,SRF55V01,SRF55V02,SRF55V10	USB virtual RS232
CR501F	Mode A+Mode B+Mode D	RS232
CR501FU	Mode A+Mode B+Mode D	USB virtual RS232
CR501AU-Desfire	MifareS50,S70,ultraLight,Desfire EV1(3DES)	USB virtral RS232
CR6403 CR510	TYPEA(Mifare Plus,Ultralight C) + TYPEB+ ISO15693 + Smart Card

Service:

1. High quality

2. Competitive price

3. 24 Hours Quickly Feedback

4. Free SDK

5. ODM/OEM Customized Design

Similar Product List for reference

Model	Description	IntterFace
CR508AU/CR608-02AU01	4BYTE UID 8HEX outPut	USB Emulation Keyboard
CR508AU/CR608-02AU	USB emulation Keyboard
CR508AU/CR608-02AU03	7BYTE UID 14HEX outPut	Ultralight,desfire,ultraligh c
CR508AU/CR608-02AU03	4 Or 7BYTE UID , 8 Or 14HEX outPut
CR508DU 01	8UID 16 Hex output	Eg: de sent out E0 04 ….
CR508DU 02	8UID 16 Hex output	Eg: de sent out …04 E0
CR508DU 03	PicoPass2k UID Hex ou
